- Size: 1.82*1.31*1.07
- Place of Origin: Shandong Port
- Brand Name: Sameng
- Model Number: 1390
- Weight: 350.000 kg
Applicable materials:
Wood, Balsa, Timber, Veneer, Bamboo, Glass, Garments plastics, Acrylic, Crytal, Glass, Leather, MDF, Paper, Plastic, Plexiglax, Plywood, Rubber,Other nonmetal materials.
Product Parameters
Laser type | Sealed CO2 laser tube |
Laser power | 60W |
Cutting area | 1300*900mm |
Resetting position accuracy | /-0.05mm |
Working voltage | AC110-220V /-10%.50-60HZ |
Power | 1500W max |
Operating temperature | 0-45 degree |
Operating humidity | 5-95% |
Minimum shaping character | English 1*1mm |
Graphic format supported | BMP, PLT, DST, DXF, and AI |
Driving system | Leadshine stepper Driving |
Cooling mode | Water-cooling and protection system |
Auxiliary equipment | Exhaust-fan, air-exhaust pipe, Air compressor |
Controlling system | DSP control system—MPC6515 |
Compatible software | Coreldraw auto CAD photoshop |
Whole machine size | 1820*1310*1070mm |
Machine Weight | 350Kgs |
Packaging & Delivery
Packaging Details: Wood Pakages
Delivery Time:Within 20 days
