- Size: 1500*1300*200mm
- Place of Origin: Shandong China
- Brand Name: Sameng
- Model Number: 1530
- Weight: 3000.000 kg
Product Parameters
X Working Area | 1500mm(5 feet) |
Y Working Area | 3000mm(10 feet0 |
Z Working Area | 200mm |
Table size | 2180x4500mm |
Machine table | Vacuum table |
Repositioning Positioning Accuracy | ±0.05mm |
X,Y ,Z Structure | XY gear wheel, Z ball screw. All Axis use Square Guide |
Max. Power Consumption(Without spindle) | 1.84KW |
Max. Rapid Travel Rate | 50000mm/min |
Max. Working Speed | 25000mm/min |
Spindle | 9kw HSD air cooled ATC spindle |
Spindle Speed | 0-18000rpm |
Drive Motor | China Servo system |
Command | G-code*.u00*.mmg*.plt |
Working voltage | 3PH AC380V/50Hz |
Control System | NK200 |
Guide rail | 25 Square rail |
Control cabinet | Independent cabinet |
N.W./G.W. | 2500/3000KGS |
Packing Size | 430 X 230 X 210cm |
- Size: 1500*1300*200mm
- Place of Origin: Shandong China
- Brand Name: Sameng
- Model Number: 1530
- Weight: 3000.000 kg
