- Size: 1300*2500*200mm
- Place of Origin: shandong China
- Brand Name: Sameng
- Model Number: 1325
- Weight: 1700.000 kg
1.Application:
Mainly used for advertising industry,wood furniture industry like processing wood door,cabinet door,art and craft door,MDF engraving,wood board engraving and processing other nonmetal materials,such as acrylic,pvc,ect.
2.Description & Specifications:
X Working Area | 1300mm |
Y Working Area | 2500mm |
Z Working Area | 200mm |
Machine table | T-slot |
Traveling Positioning Accuracy | ±0.05mm |
Repositioning Positioning Accuracy | ±0.02mm |
X,Y ,Z Structure | XY Gear Wheel Z ball screw |
Max. Power Consumption(Without spindle) | 0.8KW |
Max. Rapid Travel Rate | 25000mm/min |
Max. Working Speed | 15000mm/min |
Spindle | 3kw water cooled spindle |
Spindle Speed | 0-24000rpm |
Drive Motor | Stepper system |
Command | G-code*.u00*.mmg*.plt |
Working voltage | AC220V/50Hz-60HZ |
Control System | Ncstudio |
Control cabinet | Independent control box |
3.Packaging & Delivery:
Packaging Details:Wood packages
Dlivery Time:Wihin 20 days
