- Place of Origin: China
- Brand Name: Sameng
- Model Number: SM6090
- Weight: 200.000 kg
Laser power 40w,60w,80w,100w,130w,150w
Table type blade shape table/honeycomb table
Warranty 1 year
Cutting/engraving accuracy 0.05mm
Control system Leetro MPC6515/6535/6565
Laser tube brand Reci brand
Software Lasercut 5.3
Compatible software AutoCAD, Photoshop,Coredraw
Software operating circumstance Windows XP, Windows7 64bit/32bit
Cutting speed 24m/min
Engraving speed 60m/min
Transmission system Hiwin guiding system
Working voltage AC110V-220V,50-60HZ
Belt Shanghai Folong brand
Driving system Leadshine Stepper driver/ Panasonic servo
Cooling system Water chiller CW3000/CW5000(optional)
Dust removing system Exhaust Fan
Wearing parts laser tube, focus lens,reflect mirror
Market USA,Australia, Sweden,Turkey,Algeria,Morocco,Hungary,Mexico,Chile,Ghana
- Place of Origin: China
- Brand Name: Sameng
- Model Number: SM6090
- Weight: 200.000 kg
Technical data:
Laser type | Sealed CO2 laser tube |
Model type | SM-6090 |
Laser power | 60W 80W 100W 130W 150W (optional) |
Cutting area | 60*90cm |
Cutting speed | 0-24,000mm/min |
Resetting accuracy | ±0.05mm |
Working voltage | AC110-220V ±10%,50-60HZ |
Power | Max 1,000W |
Operating temperature | 0-45 degree |
Operating humidity | 5-95% |
Minimum shaping character | English 1*1mm |
Graphic format supported | BMP, PLT, DST, DXF, and AI |
Driving system | Stepper |
Cooling mode | Water-cooling and protection system |
Auxiliary equipment | Exhaust-fan, air-exhaust pipe, air compressor |
Controlling software | Laser cut 5.3 |
Compatible software | Coreldraw AutoCAD Photoshop |
Control system | DSP CONTROL |
Whole machine size | 1360*1010*1070mm |
Total weight with package | 200KGS |
