- Size: 3.5*2.2*1.7
- Place of Origin: China,shandong
- Brand Name: Sameng
- Model Number: 1325
- Weight: 1200.000 kg
1.Product Parameters
X Working Area | 1300mm |
Y Working Area | 2500mm |
Z Working Area | 200mm |
Machine table | Vacuum table |
Traveling Positioning Accuracy | ±0.05mm |
Repositioning Positioning Accuracy | ±0.02mm |
X,Y ,Z Structure | XY Gear Wheel Z ball screw |
Max. Power Consumption(Without spindle) | 0.8KW |
Max. Rapid Travel Rate | 30000mm/min |
Max. Working Speed | 25000mm/min |
Spindle | 4.5kw air cooled spindle |
Spindle Speed | 0-18000rpm |
Drive Motor | Stepper system-high speed Yako 2D811 driver, fast speed |
Command | G-code*.u00*.mmg*.plt |
Working voltage | AC380V/50Hz-60HZ or 220V |
Control System | DSP offline control, easy operation |
Control cabinet | Independent control box |
2.Packaging & Delivery
Packaging Details:Wood packages
Delivery Time:Within 20 days
- Size: 3.5*2.2*1.7
- Place of Origin: China,shandong
- Brand Name: Sameng
- Model Number: 1325
- Weight: 1200.000 kg
