- Place of Origin: Jinan,Shandong
- Brand Name: Sameng
- Model Number: 1625
Features:
High speed: Only need 80 seconds to finish one set of car foot mat., only need 6 minutes to finish one set of car cushion mattress
High efficiency: don't need any die mould, or die mould cutting machine, this machine can press mark, cutting and moulding on soft material such as leather, carton etc. Save much labor and cost.
Low cost: one machine can do design, cutting instead of manual design and cutting, save labor, and material wastage cost.
Wide application: This machine can cut leather, PU, fiber, EVA, XPE, sponge cladding, composite cladding, Sponge drape composite leather, PVC foot mat, paper, carton, plastic board etc. Soft material.
Good performance: adopt Taiwan TBI ball screw or Wuxi High precision rack pinion, low noise, accurate transmission. Long lifespan and high precision.
- Place of Origin: Jinan,Shandong
- Brand Name: Sameng
- Model Number: 1625
Description & Specifications: | |
X working size | 1600mm |
Y working size | 2500mm |
Z working size | 50mm |
Features | With roller and knife cutting head, suitable for package carton box cutting |
Display way | English LED touch screen |
Machine table | Suction Table |
Data transfer way | Intel |
Cutting blade | Oscillatory blade made by ourself |
Driving system | Japan Fuji servo driver and motor |
Control system | 6 axis controller |
Guiding system | Taiwan TBI 20 |
Transmission | Y rack pinion, XZ synchronous steel belt |
Cutting speed | 30m/min |
Traveling speed | 50m/min |
