- Place of Origin: China
- Brand Name: Sameng
- Model Number: 2018/1315/2015/3015
- Weight: 1500.000 kg
How many heads? 8-16 spindles depends on you
What size? 2000*1800mm/2000*1500mm/3000*1500mm/1300*2500mm ……
What kind of color? IT^S UP TO YOU
CHOOSE US IS YOUR BEST DECISION
another size: SM2018
table size: 2200*1850mm
XY working area: 2000*1800mm
Z working area: 150mm
working accuracy: 0.05mm
repositioning accuracy: 0.05mm
frame structure: whole steel structure
table type: T-slot
Max. travelling speed: 25000mm/min
Max. working speed: 15000mm/min
interface: USB
working voltage: 3PH AC380V/50HZ
spindle power: 1.5KW/2.2KW water cooling
spindle rotating speed: 0-24000rpm
drive motor: stepper
- Place of Origin: China
- Brand Name: Sameng
- Model Number: 2018/1315/2015/3015
- Weight: 1500.000 kg
another size: SM2025
X Working Area | 2000mm |
Y Working Area | 2500mm |
Z Working Area | 200mm |
Machine table | T-slot |
Traveling Positioning Accuracy | ±0.05mm |
Repositioning Positioning Accuracy | ±0.05mm |
X,Y ,Z Structure | XY gear wheel, Z ball screw. All Axis use Square Guide |
Max. Rapid Travel Rate | 15000mm/min |
Max. Working Speed | 12000mm/min |
Spindle | 1.5kw water cooled spindle*8 piece ER16 |
Spindle Speed | 0-24000rpm |
Drive Motor | XZ leadshine servo hbs 758 Y leadshine stepper M860 |
Command | G-code*.u00*.mmg*.plt |
Working voltage | 3PH AC220V/50Hz |
Control System | Nc studio V8 53C (original) |
Control cabinet | computer cabinet |
