Product Details
- Place of Origin: China
- Brand Name: Sameng
- Model Number: SM1325
| Model: | SM1325 cnc router(3KW water cooled spindle) |
| Gross weight: | 1250KGS |
| Net weight: | 1100KGS |
| Working size: | 1300*2500*2000mm |
| Table surface： | PVC & Aluminum T-slot |
| Table structure: | Cast steel |
| Transmission: | Rack and pinion,square guide rail |
| Collect: | ER20 |
| Spindle rotating speed: | 0-24000rpm |
| resolution: | 0.01mm |
| Inverter: | XFT |
| Max.rapid travel speed: | 25000mm/min |
| Spindle power: | 3KW water cooling |
| Max.working speed: | 15000mm/min |
| Diameter: | 3.175-12.7mm |
| Motor system: | Stepper leadershine 450A |
| Drive system: | Leadshine(860) |
| Control system: | NC studio control system(5.4.53) |
| Cutters: | 10 cutters |
| Voltage: | AC 50HZ 3-PHASE380V |
| Software & Working data: | Type 3,Artcam(license/copy),8GB |
| Packaging size: | 3.2*2.1*1.8m |
| Extra parts with extra price: | Vacuum worktable and Dust collector |
- Place of Origin: China
- Brand Name: Sameng
- Model Number: SM1325
Applicable industry:
sheet plane
three-dimensional wave board processing
screen
craft fan window processing
cabinet doors
solid wood door
craft door
paint-free door carving
cutting
engraving
drilling
and other processing
Other industry:
building model
wooden model
wooden aviation model
propeller
car foam mold
violin
erhu
other instruments
three-dimensional surface
shape cutting
surface pattern carved musical instruments
calligraphy plaque
carved frame
