- Place of Origin: China
- Brand Name: Sameng
- Model Number: 1530
- Weight: 900.000 kg
Standard configuration:
Working Area: 1450mm*3000mm
Lathe: with water tank
Driving Mode: Stepper
Control system: START control system (Independent machine box)
Transmitting way: pick and pinion transmitting
Guide Rail: imported square linear guide rail
Z axis height adjusting method: Arc Voltage adjust automatically
Plasma Power: 100A
Parts Consumption Quantity: Demostic 10 sets (electrode nozzle)
Software: Wentai, type3
- Place of Origin: China
- Brand Name: Sameng
- Model Number: 1530
- Weight: 900.000 kg
Technical Parameter
Model | SX-1530 |
X,Y working area | 1450mm*3000mm |
Z working area | 150mm |
Lathe bed | steel structure with water sink |
Machine Power | 8.5kw |
Working voltage | 380V/50HZ |
Reposition precision | ±0.05mm |
Processing precision | ±0.1mm |
Maximum cutting speed | 8m/min |
Torch Height control mode | Automatically |
Cutting thickness | 5-15mm |
Plasma power supply | 100A |
Control system | DSP |
Motors | Stepper |
Software | Wentai |
Weight | 800kg |
