- Size: 13
- Place of Origin: China
- Brand Name: Sameng
- Model Number: SM1325
- Weight: 1200.000 kg
Application:
Appliable for advertising, model, presents, wood construction architecture model etc.
Features:
1) It adopts advanced DSP numerical control system. It has the characteristic of operated with the handle, largescreen display, convenient operation, and easy maintenance, designed with more human nature.
2) The CNC Router adopts unique intelligent calculation method. It fully develops the potential of motor and leads to high processing speed. The Max. Speed will reach to 12000mm/min. Meanwhile it is synchronization of curve and straight lines. So it can get the good effort and make the curves smoothly.
3) This machine has the characteristic of unique dynamic renewal system. This has the characteristic of unique dynamic renewal system. The customer can change the operation ability of system accord to the different requirement.
4) The CNC ROUTER has 32M saving capacity. It can store more than 3 processing files simultaneously and read one at random.
5) The CNC ROUTER connects with the computer via USB interface. It enables data to be transimitted in a second. It can work under the system Window 98/ NT/2000/XP
6) This machine has the characteristic of good compatibility. It can work under compatible software CAD/CAW; Such as Typ3, Actcarm, casmate, Wentai, Coredraw. It can manufacture fancy embossment relief, shadow and 3D arts.
7) This machine has the performance for continuing engraving after point break and blade break and without electrical. It can hold more than 9 points and engrave anywhere
Standard Configuration:
Seamless Steel Structure
Round Guide Rail
Rack Pinion Transmitting
1.5KW water cooling spindle
DSP control system
Software: Wentai Type3
20 cutters(¢3.175, ¢4, ¢6) 3 cutter collector
Power: AC220V/50HZ
Spindle Speed: 0-24000 rpm
Motor: Stepper
- Size: 13
- Place of Origin: China
- Brand Name: Sameng
- Model Number: SM1325
- Weight: 1200.000 kg
Technical Parameter:
No. | Description | Parameter |
1 | X,Y working area | 1300*2500mm |
2 | Z working area | 200mm |
3 | Working Accuracy | 0.05mm |
4 | Repositioning Accuracy | 0.05mm |
5 | Frame Structure | Welding Steel structure |
6 | Table type | T-Slot |
7 | Max traveling speed | 50000mm/min |
8 | Max working speed | 25000mm/min |
9 | Interface | COM32 |
10 | Command | G code file, *.U00, *.plt,*.mmg,*.nc |
11 | Surroundings for software | Windows 98/2000/XP |
12 | Working voltage | 3PH AC380V/50HZ |
13 | Spindle rotating speed | 0-24000rpm/min |
14 | Drive Motor | stepper motor |
15 | Carving diameter | 3.175/4/12.7mm |
16 | Operation system | ncstudio or dsp |
17 | Spindle | 3 KW water cooling spindle |
18 | Gross weight | 1200kg |
19 | Packing Size | 320*230*190cm |
